    Outdoor P10 Full Color LED Display Sign , LED Billboard For Advertising

    Ask Lasest Price
    Brand Name : Jinhe
    Model Number : P10
    Certification : CE/ROHS/FCC
    Price : Negotiable
    Payment Terms : T/T, Western Union
    Supply Ability : 2,000 square meters per month
    Delivery Time : 15 working days after receiving deposit
    • Product Details
    • Company Profile

    Outdoor P10 Full Color LED Display Sign , LED Billboard For Advertising

    Outdoor P10 Full Color LED Display Sign,LED Billboard For Advertising


    Specifications

    Newest design DIP P10 outdoor advertising led screen display
    1. Long lifespan
    2. Hi-Brightness
    3. Fast delivery
    4. CE,FCC,ROHS

    Products details:


    Newest design DIP P10 HD outdoor advertising led screen display
    1. Long lifespan
    2. Hi-Brightness
    3. Fast delivery
    4. CE,FCC,ROHS


    Parameters:

    ItemParameter
    PixelPhysical pixel pitch: 10 mm
    Pixel configuration: 1R1PG1PBChipWaveBrightnessPacking
    ROpto620-625nm750mcdSMD-5050
    GSilan520+/_1.25nm170mcdSMD-5050
    BSilan
    470+/_1.25nm
    390mcdSMD-5050
    ModuleModule size: 160 x 160 mm

    Module resolution: 16 x 16 pixel
    CabinetCabinet size: 640 x 480 x 150 mm
    Physical resolution: 16 x 16 pixels
    Physical density: 3072 pixels/cabinet
    Module quantity: 12 pcs
    Material: Steel
    Weight: 17Kg
    Power supply(5V40A)quantity: 2pcs
    Average power consumption: 150W
    Max power consumption: 300W
    Electricity parameterBrightness: ≥ 7500 nits
    Brightness adjusted: 100 grade by software, or by Auto-optic induced
    Color processing: 16bit
    Display color: 280 trillion
    Color temperature(k): 5000 — 9500 (choice by user)
    Physical density: 10000 pixels/m2
    Whole display flatness: ≤ 1mm juncture
    Best view distance: ≥ 7m
    Best view angle: Horizontal ±80°, Vertical ±80°
    Storage temperature: -35°C ~ +85°C Working temperature: -20°C ~ +50°C
    Driving method: Constant driving current Scan: 1/4
    Refresh frequency: ≥ 400Hz
    Frame rate: ≥ 60Hz
    Humidity(RH): ≤ 90~95%
    Protection grade: IP65
    Power supply: AC 110 / 220V, 50/60Hz
    Average power consumption: 450W
    Max power consumption: 900W
    MTBF: 10, 000 hours
    Screen lifetime: 100, 000 hours
    Control systemControl system: Linsn
    Signal interface: DVI
    Communication distance: Internet cable: ≤120m Fiber cable: 1000m

    Signal transfer mode: Pixels to pixels display synchronized


    Trade Terms:
    1. Payment: T/T , 35% deposits before production, 65% balance to be paid before dleiverying (Western Union or Moneygram are welcomed)
    2. Production lead time for 100~500pcs: 10days, 500~1000pcs:15days
    3. Sample can be delivered in 3days
    4. Shipping freight are quoted under your requests
    5. Shipping port: Shenzhen, Mainland China
    6. Discounts are offered based on order quantities
    7. MOQ:1 suqare meters

    Our service:
    1. Your inquiry related to our products or prices will be replied in 24hrs.
    2. Well-trained and experienced staffs to answer all your enquires in fluent English .
    3. OEM&ODM, any your customized screen we can help you to design and put into product.
    4. Distributoer ship are offered for your unique design and some our current models .
    5. Protection of your sales area, ideas of design and all your private information .


    FAQ

    Q1: How would I do when something was wrong with the led display screen?

    A1: Professional engineers would offer onsite maintenance to your country.

    Q2: How would I select LED screen that I need?

    A2: The lower Pixel pitch,the more density,the more clear,the more expensive as well.

    Q3: Where LED screen can be applied?

    A3: It is seen everywhere in your life.Billboard,Shopping Mall advertising;bank queue system,taxi top board ,stage background display and more


    Pre-sale service:

    1. Reply enquiries in 24 hours.

    2. Market research and forecast for customer.

    3. Provide unique and professional solutions based on customer's requirement.

    4. Data sheet and samples offer.

    5. Other services, such as special packing design, factory visiting and so on.


    In-sale service:

    1. Tracking report in producing.

    2. Quality test report for every order.

    3. Photos and videos as per customer's requirement.

    4. Free spare parts.


    After-sale service:

    1. Lifetime free maintenance and upgrade.

    2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.

    3. Customer satisfaction tracking report.

    4. Free technician training.

    5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.

    6. Special service for big project, such as stadium, exhibitions, squares and so on.
